Product parameters
The dock oil hose exceeds the basic requirements of all International rules because their construction is a direct derivate of designs, technology and quality control procedures used in the building of marine hoses for offshore application, with long operational life and total environmental safety in mind.
It is used for crude oil and liquid petroleum products delivery to tankers and bunkering vessels. Max 55% aromatic content resistance. Electrically continuous (discontinuous on request).
Inner Tube: Black NBR.
Cover: Black CR-abrasion, ozone, sea water and hydrocarbon resistant. Safe factory: 4:1.
Reinforcement: High tensile textile cords.
Temperature: -20 °C to +82 °C (-4 °F to +180 °F).
| Dock Oil Hose Technical Specification | ||||||||||
| PRAT NO. | ID | OD | Working Pressure | Burst Pressure | Vacuum | Bending Radius | Weight | |||
| inch | mm | mm | bar | Psi | bar | Psi | bar | mm | kg/m | |
| DOH-0051 | 2 | 51 | 71 | 15 | 225 | 60 | 900 | 0.9 | 300 | 2.79 |
| DOH-0076 | 3 | 76 | 96 | 15 | 225 | 60 | 900 | 0.9 | 420 | 4.10 |
| DOH-0102 | 4 | 102 | 132 | 15 | 225 | 50 | 900 | 0.9 | 560 | 7.61 |
| DOH-0152 | 6 | 152 | 188 | 15 | 225 | 60 | 900 | 0.9 | 850 | 16.42 |
| DOH-0203 | 8 | 203 | 249 | 15 | 255 | 50 | 900 | 0.9 | 1100 | 26.80 |
